optris::Frame Class Reference

Represents a data frame received from a device. More...

#include <Frame.h>

Inheritance diagram for optris::Frame:

Collaboration diagram for optris::Frame:

Public Member Functions
OTC_SDK_API	Frame () noexcept
	Constructor.
OTC_SDK_API	Frame (const Frame &)=default
	Copy constructor.
OTC_SDK_API Frame &	operator= (const Frame &)=default
	Copy assignment.
OTC_SDK_API	Frame (Frame &&)=default
	Move constructor.
OTC_SDK_API Frame &	operator= (Frame &&)=default
	Move assignment.
virtual OTC_SDK_API	~Frame () noexcept=default
	Destructor.
OTC_SDK_API unsigned short	getValue (int index) const noexcept(false)
	Returns the frame data value at the given index.
OTC_SDK_API unsigned short	getValue (int x, int y) const noexcept(false)
	Returns the frame data value at the given coordinates.
OTC_SDK_API ConstFrameIterator	getConstIterator () const noexcept
	Returns an iterator with read access.
OTC_SDK_API int	getWidth () const noexcept
	Returns the width in pixels of the frame.
OTC_SDK_API int	getHeight () const noexcept
	Returns the height in pixel of the frame.
OTC_SDK_API int	getSize () const noexcept
	Returns the overall size in pixels of the frame (width * height).
OTC_SDK_API bool	isEmpty () const noexcept
	Returns whether the frame is empty.
OTC_SDK_API void	clear ()
	Clears the frame data.
OTC_SDK_API void	resize (int width, int height)
	Resizes the frame.
OTC_SDK_API Frame	clone () const noexcept
	Returns a complete copy of this frame.
OTC_SDK_API void	setData (const unsigned short *source)
	Sets the frame data values.
OTC_SDK_API void	setFromRawData (const void *source)
	Sets the frame data values from raw data.
OTC_SDK_API void	copyDataTo (unsigned short *destination, int size) const noexcept
	Copies the internal values to the destination array.
OTC_SDK_API const unsigned short *	getData () const noexcept
	Returns a pointer to the first element of the internal value array.

Protected Attributes
std::vector< unsigned short >	_values
	Frame data.

Friends
class	ConstFrameIterator

Detailed Description

Represents a data frame received from a device.

The encapsulated data may represent thermal or energy measurements in an internal format. See the specialized child classes like ThermalFrame for more details.

The origin of coordinates is located in the upper left corner with the x-axis pointing right and the y-axis pointing down.

Member Function Documentation

clone()

Frame optris::Frame::clone ( ) const

inlinenoexcept

Returns a complete copy of this frame.

Returns

a complete copy of this frame.

copyDataTo()

OTC_SDK_API void optris::Frame::copyDataTo ( unsigned short * destination, int size ) const

noexcept

Copies the internal values to the destination array.

Warning

Make sure the destination arrays has at least the size returned by getSize().

Parameters

[out]	destination	array to copy the internal data to.
[in]	size	in bytes. The specified size is limited to [0, frame size in bytes].

getConstIterator()

ConstFrameIterator optris::Frame::getConstIterator ( ) const

inlinenoexcept

Returns an iterator with read access.

The iterator traverses the frame in a row major fashion.

Returns

iterator with read access.

getData()

const unsigned short * optris::Frame::getData ( ) const

inlinenoexcept

Returns a pointer to the first element of the internal value array.

Returns

pointer to the first element of the internal value array.

getHeight()

int optris::Frame::getHeight ( ) const

inlinenoexcept

Returns the height in pixel of the frame.

Returns

height in pixels of the frame.

getSize()

int optris::Frame::getSize ( ) const

inlinenoexcept

Returns the overall size in pixels of the frame (width * height).

Returns

size in pixels of the frame.

getValue() [1/2]

OTC_SDK_API unsigned short optris::Frame::getValue

(

int

index

)

const

Returns the frame data value at the given index.

Parameters

[in]

index

of the desired frame data.

Returns

frame data value at the given index.

Exceptions

SDKException

if the index is out of range.

getValue() [2/2]

OTC_SDK_API unsigned short optris::Frame::getValue	(	int	x,
		int	y ) const

Returns the frame data value at the given coordinates.

Parameters

[in]	x	coordinate.
[in]	y	coordinate.

Returns

frame data value at the given coordinates.

Exceptions

SDKException

if the coordinates are out of range.

getWidth()

int optris::Frame::getWidth ( ) const

inlinenoexcept

Returns the width in pixels of the frame.

Returns

width in pixel of the frame.

isEmpty()

bool optris::Frame::isEmpty ( ) const

inlinenoexcept

Returns whether the frame is empty.

Returns

true if the frame is empty. False otherwise.

resize()

OTC_SDK_API void optris::Frame::resize	(	int	width,
		int	height )

Resizes the frame.

Parameters

[in]	width	of the resized frame in pixels.
[in]	height	of the resized frame in pixels.

setData()

OTC_SDK_API void optris::Frame::setData

(

const unsigned short *

source

)

Sets the frame data values.

Parameters

[in]

source

to set the frame data values from.

setFromRawData()

OTC_SDK_API void optris::Frame::setFromRawData

(

const void *

source

)

Sets the frame data values from raw data.

Parameters

[in]

source

to set the frame data values from.

---

The documentation for this class was generated from the following file:

• Frame.h
